Rated Power (MW) : 0.7-7MW
Rated thermal efficiency: ≥86%
Available fuel: Biomass pellets sawdust bagasse rice bran wood block wood chips peanut shell firewood cotton stalk fungus rhizome etc
Available industries: Heating chemical industry food tobacco textile printing and dyeing feed medicine building materials brewing rubber hospital etc.
Aiming at the characteristics of biomass fuel, our company has developed an industrial boiler adapted to biomass fuel combustion, which can avoid or solve the problems of ash accumulation and slagging in the process of biomass combustion and heat exchange.The emission of flue gas meets the relevant national environmental protection standards, and the carbon content of ash residue is low, which can realize the comprehensive utilization of fly ash.
1. Design of large furnace and new fumace arch.
2.Large combustion chamber,strong applicability of coal.
3.Reasonable exhaust distribution.
4.Good dust removal effect.
| Model | Thermal power (MW) | Supply and return water temperature (℃) | Thermal efficiency (%) | Heating area (M2) |
|---|---|---|---|---|
| CDZL0.7-85/60 | 0.7 | 85/60 | 84.9 | 8500 |
| CDZL1.4-85/60 | 1.4 | 85/60 | 85.2 | 17500 |
| CDZL2.8-85/60 | 2.8 | 85/60 | 86 | 35000 |
| CDZL4.2-85/60 | 4.2 | 85/60 | 86.4 | 36000 |
| CDZL7-85/60 | 7 | 85/60 | 86.8 | 60000 |
